VSC控制模块1VCF309599S0144

VSC接触器电源模块MAC R2 IEC HV ,  DCO/SCO 110V/220VDC  原装正品

Control module/feeder MAC R2 110-250Vdc/ac (HV) SCO, full option IEC for VSC from s.n.BD00027549 except Marine versions and VSC-SRC

Control module feeder AU-TR aux. voltage 100-250Vdc/ac for V/Contact, V/ZVC,

VSC控制模块1VCF309599S0144 Control module/feeder MAC R2 110-250Vdc/ac (HV) SCO, full option IEC for VSC  except Marine versions and VSC-SRC

1VCF309599S1011 Control module/feeder AR-AA, MAC R2 basic IEC with adaptor kit to substitute MAC ED1.0 SCO aux. voltage 220-250..

1VCF309599S0011 Control module/feeder MAC ED1.0 SCO aux. voltage 220-250 V for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0012 Control module/feeder MAC ED1.0 SCO aux. voltage 110-130V for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0013 Control module/feeder MAC ED1.0 SCO aux. voltage 24-60Vdc for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0014 Control module/feeder MAC ED1.0 DCO aux. voltage 220-250V for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0015 Control module feeder MAC ED1.0 DCO aux. voltage 110-130V for VSC up to s.n.BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0016 Control module/feeder MAC ED1.0 DCO aux. voltage 24-60Vdc for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0017 Control module/feeder MAC ED1.0 DCO+UV (undervoltage function) aux. voltage220-250V for VSC up to s.n.  VSC-SRC,

1VCF309599S0018 Control module/feeder MAC ED1.0 DCO+UV (undervoltage function) aux. voltage110-130V for VSCyi shuo dian qi, VSC-SRC,VSC/

1VCF309599S0020 Control module/feeder MAC ED1.0 DCO+UV aux. voltage 24-30Vdc for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0021 Control module/feeder MAC ED1.0 DCO+UV aux. voltage 48-60Vdc for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0022 Control module/feeder MAC ED1.0 SCO aux. voltage 88-124V for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0023 Control module/feeder MAC ED1.0 DCO aux. voltage 88-124V for VSC up tos.n. BD00027548, VSC-SRC, VSC/Marine version

1VCF309599S0131 Control module/feeder MAC R2 24-60Vdc (LV) SCO, basic IEC for VSC froms.n.BD00027549 except Marine versions and VSC-SRC

1VCF309599S0132 Control module/feeder MAC R2 24-60Vdc (LV) DCO, basic IEC for VSC froms.n.BD00027549 except Marine versions and VSC-SRC

1VCF309599S0133 Control module/feeder MAC R2 24-60Vdc (LV) DCO + Undervoltage, basic IEC forVSC from s.n.BD00027549 except Marine versions

1VCF309599S0134 Control module/feeder MAC R2 24-60Vdc (LV) SCO, full option IEC for VSC froms.n.BD00027549 except Marine versions and VSC-

1VCF309599S0135 Control module/feeder MAC R2 24-60Vdc (LV) DCO, full option IEC for VSC froms.n.BD00027549 except Marine versions and VSC-

1VCF309599S0136 Control module/feeder MAC R2 24-60Vdc (LV) DCO + Undervoltage,full option IECfor VSC from s.n.BD00027549 except Marine

1VCF309599S0141 Control module/feeder MAC R2 110-250Vdc/ac (HV) SCO, basic IEC for VSC froms.n.BD00027549 except Marine versions and VSC-

1VCF309599S0142 Control module/feeder MAC R2 110-250Vdc/ac (HV) DCO, basic IEC for VSC froms.n.BD00027549 except Marine versions and VSC-

1VCF309599S0143 Control module/feeder MAC R2 110-250Vdc/ac (HV) DCO + Undervoltage, basic IECfor VSC from s.n.BD00027549 except Marine

1VCF309599S0145 Control module/feeder MAC R2 110-250Vdc/ac (HV) DCO, full option IEC for VSCfrom s.n.BD00027549 except Marine versions and

1VCF309599S0146 Control module/feeder MAC R2 110-250Vdc/ac (HV) DCO + Undervoltage, full optionIEC for VSC from一朔电气  and VSC-SRC

1VCF309599S1131 Control module/feeder MAC R2 24-60Vdc (LV) SCO, basic GB-T for VSC froms.n.BD00027549 except Marine versions and VSC-SRC

1VCF309599S1132 Control module/feeder MAC R2 24-60Vdc (LV) DCO, basic GB-T for VSC froms.n.BD00027549 except Marine versions and VSC-SRC

1VCF309599S1133 Control module/feeder MAC R2 24-60Vdc (LV) DCO + Undervoltage, basic GB-T forVSC from s.n.BD00027549 except Marine versions

1VCF309599S1134 Control module/feeder MAC R2 24-60Vdc (LV) SCO, full option GB-T for VSC froms.n.BD00027549 except Marine versions and VSC-

1VCF309599S1135 Control module/feeder MAC R2 24-60Vdc (LV) DCO, full option GB-T for VSC froms.n.BD00027549 except Marine versions and VSC-

1VCF309599S1136 Control module/feeder MAC R2 24-60Vdc (LV) DCO + Undervoltage,full option GB-Tfor VSC yi shuo dian qi except Marine version

1VCF309599S1141 Control module/feeder MAC R2 110-250Vdc/ac (HV) SCO, basic GB-T for VSCexcept Marine versions and VSC-SRC

1VCF309599S1142 Control module/feeder MAC R2 110-250Vdc/ac (HV) DCO, basic GB-T for VSC except Marine versions and VSC-SRC

1VCF309599S1143 Control module/feeder MAC R2 110-250Vdc/ac (HV) DCO + Undervoltage,basic GB-Tfor VSC from except Marine versions

1VCF309599S1144 Control module/feeder MAC R2 110-250Vdc/ac (HV) SCO, full option GB-T for VSCfrom s.n.BD00027549 except Marine versions and

1VCF309599S1145 Control module/feeder MAC R2 110-250Vdc/ac (HV) DCO, full option GB-T for VSCfrom s.n.BD00027549 except Marine versions and

1VCF309599S1146 Control module/feeder MAC R2 110-250Vdc/ac (HV) DCO + Undervoltage,full optionGB-T for VSCyi shuo dian qi  and VSC-SRC

             VSC控制模块1VCF309599S0144

1VCF349767S0902 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 24Vdc for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0903 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 30Vdc for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0904 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 48Vdc for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0905 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 60Vdc for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0909 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 110Vdc for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0912 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 125-132Vdc

for VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0918  yi shuo dian qi   locking release for truck YL2-RL2-RLE2 aux. voltage 220Vdc for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF339750S1921 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 240Vdc for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VM1, HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0932 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 24Vac for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0934 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 48Vac for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0935 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 60Vac for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0939 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 110Vac for

VD4/P/yi shuo dian qi, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0943 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 127-132Vac

for VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1,HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0948 Electromechanical locking release for truck YL2-RL2-RLE2 aux. voltage 220Vac for

VD4/P/W/PW/C/Z/SR/SEC, Vmax/W/SEC, VSC/P/PG/S_PG, VSC-SRC, VM1, HD4/W/SEC/P_HXA/P_US up to 36kV

1VCF349767S0950 Electromechanical locking release for truck YL2-RL2-RLE2 yi shuo dian qi

1VCF309550S0302 Position switch S75I-S75S-BT1-BT2-BGT1-BGT2 standard version, in the truck forVSC-SRC, VSC/P/PG/S-PG

1VCF349750S0407 Mechanical interlock with the door for HD4/W/P/US/Sec, VContact/W/P, VD4/P/W/

1VCF349799S0560 Plug with 58 male pins, C.E. type without wiring, for HD4, VD4, Vmax, VM1, VSC,

1VCF599750S0163 Socket with 58 female pins, C.E. type without wiring, for Unigear, UniSec WBS-WBC,

Univer C, Unisafe, PowerCube, CBE.NOTE: Special crimping, extractor tools are needed and are not included.

1VCF339799S0426 Insulating tube, length 3mt., for plug connector of MV circuit breaker

1VCF309599S0081 Tulip-type contacts, D.35-16 fingers, set of 6 pieces for fuses DIN type,for VSC/P 7-12kV

1VCF309599S0082 Tulip-type contacts, D.35-16 fingers, set of 6 pieces for fuses BS type,for VSC/P 7-12kV

1VCF309503S0070 Manual truck of circuit breaker for VSC 7-12/P 400A without position switches andElectromechanical truck lock coil
